KONICA RF Product list

Last updated on 2026-01-21

A summary of review pages for the KONICA rangefinder camera HEXAR RF & Limited and HEXANON M-mount and L39-mount lenses.

• Please see the disclaimer regarding advertising here.
• Italicized links in the text are advertisement links that take you to other sites.
• If you find any images used on this site problematic, please contact us via the comments or inquiry form, either as the rights holder or their representative. We will review the matter and take appropriate action.

Table of contents

Camera body

• HEXAR RF
• HEXAR RF Limited

KM Lens

Item	Dual range HEXANON	HEXANON	HEXANON	HEXANON	HEXANON	HEXANON
focal length(mm)	21-35	28	35	50	50	90
Maximum aperture	3.4-4	2.8	2	2	1.2	2.8
Minimum aperture	22	22	16	16	16	22
Leaf blade	10	10	10	10	12	10
Lens configuration	8 elements in 6 groups	8 elements in 7 groups	8 elements in 7 groups	6 elements in 5 groups	7 elements in 6 groups	5 elements in 4 groups
Minimum distance(m)	0.8	0.7	0.7	0.7	0.9	1.0
Lens length(mm)	0.8	40.4	45.1	43.5	50	69
Lens max diameter(mm)	57	52	55.7	54	68.8	55
Filter type	68	46	46	40.5	62	46
Weight(g)	62	230	260	255	390	330
Hood	Bayonet	Slitted cylinder, screw-in	Slitted cylinder, screw-in	Build in	Slitted cylinder, screw-in	Build in
Lens mount	M-mount Compatible	M-mount Compatible	M-mount Compatible	M-mount Compatible	M-mount Compatible	M-mount Compatible
Release date	2002	1999	2000	1999	2001	1999

L39 Lens

Item	L HEXANON	UC-HEXANON Black	L HEXANON	L HEXANON	L HEXANON
focal length(mm)	35	35	50	50	60
Maximum aperture	2	2	2.4	1.9	1.2
Minimum aperture	16	16	16	22	16
Leaf blade	10	10	10	10	10
Lens configuration	7 elements in 6 groups	7 elements in 6 groups	6 elements in 4 groups	6 elements in 4 groups	7 elements in 6 groups
Minimum distance(m)	0.9	0.9	1	0.8	1
Lens length(mm)	28.5	26.5	29.3	52	51.5
Lens max diameter(mm)	54	51	51	52	65
Filter type	46	43	40.5	39.5	58
Weight(g)	145	120	200	270	420
Hood	Trumpet type, screw-in	Slitted cylinder, screw-in	Trumpet type, screw-in	–	Slitted cylinder, screw-in
Lens mount	KL	KL	KL	KL	KL
Release date	1996	2001	1997	1955	1999

Regarding unowned lenses

• HEXANON Dual lens 21-35
  • Since it’s an old zoom lens, I heard that the aberration correction isn’t very good and results in distortion, so I didn’t buy it.
  • With a rangefinder camera, it’s not that much of a hassle to carry around a 21mm and a 35mm lens separately, so the purpose of this lens is questionable, but I would have liked a 21mm prime lens that pursued optical performance.
• UC HEXANON 35
  • I had several chances to purchase this lens, but I didn’t because I already owned the silver HEXANON 35mm F2.
  • As of 2024, used prices have skyrocketed, so I’m not sure if it’s worth the money.
